Bases are the foundation for the B-RAD system and the rest of the B-RAD system mounts to them

  • Reposition bottle cages using existing bottle cage mounts on your bike

  • Lightweight, durable, rust-proof materials

  • Customize storage to your specific needs with flexible B-RAD system

B-RAD 2
  • The 2-Slot Base can move bottle or other accessory to an optimal location even on a smaller or dual suspension frame
  • B-RAD 2 base instructions
B-RAD 3
  • The 3 slot base with 4 threaded holes provides additional adjustment and mounting options vs the B-RAD 2. A typical application would be to mount a bottle cage in the forward threaded holes with a B-RAD accessory tucked behind it. This mounts perfectly to triple bottle mounts on frames and forks. The B-RAD 3 includes a zip tie, channels for the zip tie, and a foam pad for secure mounting
  • B-RAD 3 base instructions
B-RAD 4
  • The 4 slot base is the longest base with 9 threaded holes for the ultimate flexibility and capacity when bike packing, touring, commuting or just exploring on 2 wheels. It′s long enough to mount 2 small bottles inline or multiple accessories. The B-RAD 4 includes zip ties, channels for the zip ties, and a foam pad for secure mounting
  • B-RAD 4 base instructions
    DOGBONE
    • The Dogbone can be used to offset a bottle or other accessory to an optimal location. Most commonly used for smaller, curved or dual suspension frames
    • Dogbone base instructions



      Compatibility

      • Mounting any of the bases requires the use of at least 2 standard threaded bottle cage mounts. B-RAD 3 and 4 should use the auxiliary foam pad (to protect your frame) and zip tie to secure the base. Any other mounting methods are not recommended
      • You may need a Problem Solvers Space Out Kit or similar method to clear the front derailleur clamp. Be sure to use bolts with additional length equivalent to the extra spacing added.
      • Compatible with any frame that uses standard 64mm spacing bottle cage braze-ons (basically every modern frame)




      Related Products

      Tech Specs

      Weight: B-RAD 2 • 27g |  B-RAD 3 • 41g |  B-RAD 4 • 75g  |  Dogbone • 10g
      Material:  6061-T6 aluminum brackets  |  EVA foam pad
      Torque: 3-4 Nm
      Max Load: 1700g per base
      Made in the USA

        WARNING Handling this product will expose you to chemicals, including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For further information go to www.P65Warnings.ca.gov.​

      Patent and trademark information

      —   —   —   —   —   —   —   —   —   —   —   —

      B-RAD™ — BOTTLE RELOCATION & ACCESSORY DEVICE
      An innovative, flexible system for organizing on-bike bottle storage and accessories

      Customize storage to your specific needs with flexible 3-step B-RAD system.

      Here is how it works:

      B-RAD Base – available in a variety of lengths

      • Attaches to bottle cage mounts on bike
      • Provides platform for the B-RAD system

       B-RAD Mount

      • Attaches to B-RAD Base
      • Secures accessories to the Base
      • Accessory-specific mounts available

       Accessories

      • Held in place by B-RAD mounts or straps
      • Carry ride essentials like bottles or tools
