Aero Direct Mount Chainrings for Shimano Dura-Ace R9200 Cranks
110DP4-R-S-02N-46A
Pairs Well With
Aero Direct Mount Chainrings for Shimano Dura-Ace R9200 Cranks
Designed for racing, and for those looking to optimize each detail in pursuit of speed, Wolf Tooth Aero Chainrings are strong, lightweight, and profiled to mate perfectly with your crankset for a clean, integrated look. Taking advantage of 1x drivetrain systems and wider-range rear cassettes, Aero Chainrings for Shimano Dura-Ace R9200 cranks are available in sizes 46T to 50T to provide similar overall range to standard 2x drivetrain configurations. They feature our patented Drop-Stop® ST tooth profile optimized for the Shimano 12-speed Hyperglide+ chain for the best wear life, chain retention, and mud clearance.
Compatibility
- Available in sizes 46T - 50T
- Compatible with Shimano R9200 cranks (FC-R9200 and FC-R9200-P)
- NOT compatible with Ultegra R8100, 105 R7100, and any other Shimano cranks
- Drop-Stop ST is optimized for Shimano 12-speed Hyperglide+ chains
- Wolf Tooth’s patented Drop-Stop wide/narrow tooth profile provides the ultimate chain retention and efficiency
- Our chainrings are designed for 1x drivetrains. They are not compatible with 2x drivetrains
- 4 bolts are included. Torque to 5 Nm.
Recommendations
- If you plan to ride in very muddy conditions, we recommend a chain guide or chain keeper in addition to a clutch-type rear derailleur. Without these precautions, you may experience chain drops and/or chain suck.
Related Products
Tanpan - allows Shimano mountain bike rear derailleurs to be used with Shimano road shifters
RoadLink - allows for wide range of cassettes to be used with Shimano road rear derailleurs
Tech Specs
Weight: 46t Aero • 137g | 48t Aero • 148g | 50t Aero • 163g
Material: 7075-T6 aluminum
Included: 4 bolts
Chainline: Variable
Made in the USA
